Plumbing Merit Badge Pamphlet Plumbing Merit Badge

Plumbing


Requirements were REVISED effective January 1, 2017.

To see the changes which were made, Click here.

For the previous requirements, Click here.


  1. Do the following:
    1. Describe how a properly working plumbing system protects your family's health and safety.
    2. List five important local health regulations related to plumbing and tell how they protect health and safety.
    3. Describe the safety precautions you must take when making home plumbing repairs.
  2. Do the following:
    1. Make a drawing and explain how a home hot- and cold- water supply system works. Tell how you would make it safe from freezing.
    2. Make a drawing and explain the drainage system of the plumbing in a house. Show and explain the use of drains and vents.
  3. Show how to use five important plumber's tools.
  4. Identify and describe the use of each of the following: washer,  retaining nut, plunger (rubber force cup), solder, flux, elbow, tee, nipple, coupling, plug, union, trap, drainpipe, and water meter.
  5. Name the kinds of pipe that are used most often in a plumbing system. Explain why these pipes are used.
  6. Cut, thread, and connect two pieces of metal pipe.
  7. Under the supervision of a knowledgeable adult, solder three copper tube connections using a gas torch. Include one tee, two straight pieces, and one coupling.
  8. Do the following:
    1. Replace a washer in a faucet.
    2. Clean out a sink or lavatory trap.

BSA Advancement ID#: 86
Scoutbook ID#: 90
Requirements last updated in: 2017
Pamphlet Publication Number: 35933
Pamphlet Stock (SKU) Number: 35933
Pamphlet Revision Date: 2012


Worksheets for use in working on these requirements: Format
Word Format PDF Format


Blanks in this worksheets table appear when we do not have a worksheet for the badge that includes these requirements.
